Description

MSI PRO B650M-P AM5 Ryzen 7000 DDR5 SATA 6G 2x M.2 2.5G LAN 7.1 Audio mATX

  • Latest DDR5 Memory: A huge step of DDR performance enhancement with the latest DDR5 memory and MSI Memory Boost technology.
  • Lightning Gen4 Solution: The latest Gen4 PCI-E and M.2 solution with up to 64GB/s bandwidth for maximum transfer speed.
  • 2.5G Network Solution: Featuring premium 2.5G LAN to deliver better network experience.
  • EZ Debug LED: Easiest way to troubleshoot.
  • Frozr AI Cooling: Detect CPU & GPU temperatures and automatically adjust system fan duty to a proper value.
  • Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility.
  • Core Boost: With premium layout and fully digital power design to support more cores and provide better performance
Model
Brand MSI
Model PRO B650M-P
Supported CPU
CPU Socket Type AM5
CPU Type Supports AMD Ryzen 7000 Series Desktop Processors
Chipsets
Chipset AMD B650
Memory
Number of Memory Slots 4x288pin (DDR5)
Memory Standard Memory Support DDR5 6000+(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
– 1DPC 1R Max speed up to 6000+ MHz
– 1DPC 2R Max speed up to 6000+ MHz
– 2DPC 1R Max speed up to 6000+ MHz
– 2DPC 2R Max speed up to 6000+ MHz
Maximum Memory Supported 192GB
Channel Supported Dual Channel
ECC Supported Non-ECC
Buffer Supported Un-buffered
Memory Feature Supports AMD EXPO
Expansion Slots
PCI Express 4.0 x16 1x PCI-E x16 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI Express x1 2x PCI-E x1 slot
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
Storage Devices
SATA 6Gb/s 4 x SATA 6Gb/s
M.2 2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
SATA RAID Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Onboard Audio
Audio Chipset Realtek ALC897 Codec
7.1-Channel High Definition Audio
Audio Channels 7.1 Channels
Onboard LAN
LAN Chipset Realtek 8125BG 2.5G LAN
Max LAN Speed 2.5Gbps
Rear Panel Ports
Back I/O Ports 1 x D-Sub / 1 x DisplayPort / 1 x Flash BIOS Button / 1 x HDMI / 1 x LAN (RJ45) / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 3.2 Gen 1 Type-A / 2 x USB 3.2 Gen 2 Type-A / 3 x Audio Jacks / 4 x USB 2.0/1.1
Internal I/O Connectors
Onboard USB 4x USB 2.0 ports
2x USB 3.2 Gen1 Type A ports
1x USB 3.2 Gen2 Type C ports
Other Connectors 1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
3x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
2x Addressable V2 RGB LED connector (JARGB_V2)
2x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
Physical Spec
Form Factor Micro ATX
Dimensions (W x L) 9.6″ x 9.6″
Windows 11 Compatibility
Windows 11 Supported
Packaging
Package Contents Quick Installation Guide
2 x M.2 Clips
SATA Cable
I/O Shield
